Самовсасывающий химический насос - Центробежный насос с фторсодержащей футеровкой FZB
Сайт самовсасывающий химический насос developed by Насос Чанъюй is designed for corrosive liquid transfer where suction conditions are difficult or the fluid level is below the pump inlet.
This FZB fluorine-lined centrifugal pump from Насос Чанъюй is engineered for chemical industries requiring stable operation, corrosion resistance, and automatic self-priming capability without external priming systems.
Once initially filled, the pump can automatically evacuate air from the suction line and maintain continuous operation under demanding chemical conditions.
It is widely used in chemical processing systems where acids, alkalis, and solvents must be transferred safely and efficiently.
|
Диапазон скорости потока : |
2.5m³/h-100m³/h |
|---|---|
|
Диапазон голов: |
15m-50m |
|
Мощность двигателя : |
0.75 kw~55 kw |
|
Скорость: |
968-3450 r/min |
|
Средний диапазон температур: |
-20℃~150℃ |
|
Настраиваемые материалы: |
FEP(F46)、PFA |
Why Choose a Self-Priming Chemical Pump
In chemical plants, pumping conditions are often complex:
- Liquid tanks are installed below ground level
- Fluids are highly corrosive or volatile
- Manual priming is unsafe or inconvenient
- Leakage risk must be minimized
A самовсасывающий химический насос eliminates the need for external priming systems and reduces operational risk.
Преимущества:
- Automatic self-priming after initial filling
- Safe handling of corrosive liquids
- Reduced operator intervention
- Stable suction performance under dry-start conditions
- Suitable for closed chemical transfer systems
Принцип работы
The pump operates based on a gas-liquid separation self-priming structure.
When the pump starts, the impeller creates a vacuum in the pump chamber. Air and liquid are mixed and circulated in the separation chamber. Air is discharged through the return path, while liquid is retained inside the casing until full priming is achieved.
Once primed, the самовсасывающий химический насос operates as a standard centrifugal pump, maintaining continuous flow without interruption.
For more information on priming and starting centrifugal pumps, please read: Как заправить центробежный насос
Детали
The FZB-type fluoroplastic-lined самовсасывающий химический насос primarily consists of core components such as the fluoroplastic-lined pump body, impeller, self-priming device, shaft seal system, and drive unit. If you have specific operational conditions or selection requirements, we can provide further technical support and customized product services.
- Fluoroplastic-lined pump body: Constructed with a high-performance fluoroplastic lining, it offers excellent resistance to strong corrosive media and is suitable for various chemical liquids such as acids, alkalis, and solvents.
- Крыльчатка: Made of fluoroplastic or composite materials, it features superior corrosion resistance and hydraulic performance, enabling efficient medium transportation.
- Self-priming device: Integrated self-priming structure allows the pump to rapidly self-prime within the suction head range (e.g., 5 meters) without requiring priming liquid.
- Sealing system: Optional mechanical seals or leak-free magnetic drive systems are available to effectively prevent the leakage of hazardous media and enhance operational safety.
- Drive unit: Equipped with high-efficiency motors as standard, supporting various power ratings and explosion-proof grades to meet the needs of different industrial environments.
The wetted parts of the pump are lined with fluoroplastic materials, providing strong resistance to aggressive chemicals.
This structure allows the pump to handle:
- Strong acids (sulfuric, hydrochloric, nitric acid)
- Сильные щелочи
- Органические растворители
- Oxidizing chemical solutions
The fluorine lining isolates the metal body from direct contact with media, significantly extending service life in corrosive environments.
FZB Fluorine-lined самовсасывающий химический насос Specifications
For more detailed performance parameters or selection support, please contact our technical team.
| Модель | Расход (м³/ч) | Высота (м) | Мощность двигателя (кВт) | Скорость (об/мин) | Самовсасывающий Высота (м) | Время самовсасывания (с) | Эффективность (%) | NPSHr (м) | Вход | Розетка |
|---|---|---|---|---|---|---|---|---|---|---|
| 25FZB-20LP | 1.5-6 | 16-19 | 2.2 | 2900 | 0.7 | 180 | 10-25 | 3 | 25 | 25 |
| 40FZB-20P | 5-12 | 17-22 | 3 | 2900 | 1 | 180 | 35-46 | 3 | 40 | 50 |
| 40FZB-30L | 5-12 | 28-32 | 4 | 2900 | 3 | 150 | 34-48 | 3.5 | 40 | 50 |
| 50FZB-20P | 8-15 | 17-22 | 3 | 2900 | 1 | 180 | 35-42 | 3 | 50 | 50 |
| 50FZB-30L | 8-15 | 28-32 | 4 | 2900 | 3 | 150 | 24-30 | 3.5 | 50 | 50 |
| 50FZB-45L | 8-15 | 43-47 | 7.5 | 2900 | 3 | 150 | 24-35 | 3.5 | 50 | 40 |
| 50FZB-70L | 8-15 | 68-72 | 15 | 2900 | 3 | 150 | 20-26 | 4 | 50 | 32 |
| 65FZB-30L | 15-35 | 27-32 | 7.5 | 2900 | 3 | 200 | 37-42 | 4 | 65 | 50 |
| 65FZB-45L | 15-35 | 38-47 | 11 | 2900 | 3 | 180 | 30-44 | 4 | 65 | 40 |
| 65FZB-70L | 15-35 | 65-72 | 22 | 2900 | 3 | 180 | 30-42 | 4 | 65 | 40 |
| 80FZB-30L | 35-60 | 28-35 | 11 | 2900 | 3.5 | 180 | 51-63 | 4.5 | 80 | 65 |
| 80FZB-45L | 35-60 | 42-47 | 15 | 2900 | 3.5 | 200 | 45-53 | 4.5 | 80 | 65 |
| 80FZB-70L | 35-60 | 65-72 | 30 | 2900 | 3.5 | 250 | 43-50 | 5 | 80 | 50 |
| 100FZB-30L | 65-110 | 28-32 | 18.5 | 2900 | 3.5 | 200 | 56-80 | 6 | 100 | 80 |
| 100FZB-45L | 65-110 | 40-46 | 30 | 2900 | 4 | 250 | 48-55 | 6 | 100 | 80 |
Уведомление: Trust our industrial-grade FZB Series Самовсасывающий насос to minimize operational downtime and lower your total cost of ownership in highly corrosive chemical applications. By utilizing a horizontal self-priming structure that allows for automatic suction up to 5 meters after the initial filling and advanced fluoroplastic linings (FEP/PFA), наши разработки обеспечивают более безопасную, стабильную и герметичную среду для работы с самыми агрессивными средами.
Электронная почта: jade@changyupump.com
Телефон: +86-13651913727
Advantages of the Self-Priming Chemical Pump
Strong medium adaptability
Designed for chemical harsh conditions, handles corrosive liquids, slurry ≤5% solids, and temperatures up to 150°C.
High-efficiency self-priming and leak-free operation
Self-priming up to 5m, no priming needed, seal-less or magnetic drive ensures zero leakage.
Excellent corrosion resistance
Fluoroplastic lining resists strong acids, alkalis, and solvents, replacing titanium, Hastelloy, and Monel pumps.
Low-maintenance design
Compact modular structure, wear-resistant lining, easy maintenance, reduced downtime and operational cost.
When to Use a Self-Priming Chemical Pump
This pump is recommended for the following conditions:
- The chemical tank is installed below ground level
- Suction piping cannot be filled manually
- Frequent startup and shutdown cycles are required
- Leakage must be strictly controlled
- Continuous chemical transfer is required in closed systems
Typical installation environments include chemical storage areas, production workshops, and process circulation systems.
Приложение
The FZB-type fluoroplastic-lined self-priming Chemical pump is widely used in the following industries and applications:
- Chemical and New Materials Industry: Suitable for the transportation of corrosive media such as strong acids, strong alkalis, organic solvents, and corrosive substances in new material synthesis processes. It is particularly suitable for feedstock loading into reactors, intermediate transfer, and the transportation of high-purity chemicals, meeting the stringent requirements for corrosion resistance and zero leakage under harsh operating conditions.
- Environmental Protection and New Energy Sector: Widely used in wastewater treatment, electroplating solution circulation, collection of waste liquid from acid washing lines, transportation of electrolyte in the preparation of new energy battery materials, and flue gas desulfurization and deacidification processes, capable of withstanding corrosive and complex fluids containing trace particles.
- Biopharmaceutical and Food Engineering: Complies with GMP requirements for the transportation of pharmaceutical solutions, culture media, dilute acids and alkalis, and food-grade solvents. It can achieve clean self-priming and prevent contamination, making it suitable for tanks with liquid levels below the pump inlet, fermentation tank feeding, and CIP systems.
- Metallurgy, Electroplating, and Surface Treatment: Used in mining and metallurgy for leaching solutions and extractant transportation, in the electroplating industry for plating solutions and acid copper solution circulation, and in the dyeing industry for dye and additive addition. Effectively handles harsh environments with high temperatures, corrosion, and particulate impurities.
Comparison with Standard Chemical Pumps
| Характеристика | Самовсасывающий химический насос | Standard Chemical Pump |
|---|---|---|
| Priming requirement | Not required after first fill | Required every start |
| Installation flexibility | High | Limited |
| Dry start capability | Supported | Not recommended |
| Leakage risk | Нижний | Выше |
| Operation complexity | Simple | Moderate |
Custom Self-Priming Chemical Pump
Changyu Pump is a professional manufacturer specialising in the research, development, and production of centrifugal pumps. With 20 years of industry experience, ISO and CE certifications, and strong technical expertise, we provide customised corrosion-resistant, self-priming, high-efficiency, safe, and reliable FZB-type fluoroplastic-lined self-priming chemical pump solutions for various industries. Our team delivers professional, cost-effective pumping solutions based on your requirements. For technical consultation or product information, please contact us anytime.
To ensure precise matching of pump type and configuration, please provide the following information:
- Средние свойства: Please specify the chemical name, concentration, temperature, presence of particles (particle size and content), and corrosive characteristics of the medium to enable us to select the most suitable pump material and sealing solution.
- Operating conditions and performance requirements: Include parameters such as self-priming height, flow rate, head, inlet diameter, and system pressure, so we can determine the pump size and drive configuration accordingly.
- Application scenario and industry: Inform us of the specific application scenario (e.g., wastewater lifting, chemical transportation, pharmaceutical liquid filling, etc.) and the industry it belongs to.
- Special requirements and standards: If there are any special requirements such as explosion-proof, leak-proof ratings, material certifications (e.g., FDA, GMP), or other specific needs.
Вопросы и ответы
Фабричная выставка
Похожие блоги
Витрины проектов
